37A Moduboot Въздушни Дифузори
Автоматично и точно управление на въздушния поток
Airovision е модулна конструкция, която може да бъде напълно персонализиранa, за да осигурява необходимата ефективност за всяко приложение.
В специалните нови корпуси са използвани само висококачествени елементи, в това число филтри, системи с топлинна рекуперация, вентилаторни блокове, охлаждащи и нагревателни топлообменници, овлажнители и шумозаглушители.
Серията Airovision също така обръща особено внимание на качеството на въздуха и на ограничаването на енергията, необходима за охлаждане, затопляне, овлажняване и подаване на климатизирания въздух.
